How do you order an Inspur TS860G7 without mixing a 4-socket and an 8-socket BOM?

Quick Take

Quick Take: Write 4-socket or 8-socket on line 1 of an Inspur / IEIT TS860G7 quote. Eight CPUs can reach 480 cores and 128 DDR5 DIMMs, but 2 DPC drops memory to 4400 MT/s. A GPU row replaces half of the FHHL slots. For China enterprise RFQs, freeze socket count on the equal brief before 13% VAT special fapiao pricing with TAOHAN.

What TS860G7 Is (and Is Not)

Definition: IEIT SYSTEMS / Inspur TS860G7 is a 6U rack server for 4 or 8 sockets of 4th Gen Intel Xeon Scalable (Sapphire Rapids), chipset Intel C741. It is not a Xeon 6 box, and it is not an xFusion or Huawei relabel. On Chinese pages call it 浪潮 TS860G7; do not pitch it as a 信创 product — use 信创 only as an optional dual-path contrast.

Think of 4-socket vs 8-socket like ordering a four-engine vs eight-engine airframe: same family, different ticket. Empty sockets are not a free field upgrade unless the quote says so.

Fit: one large HANA or OLTP image that must stay in a single OS.

Unfit: a scale-out VM farm that is cheaper on several 2-socket servers.

Key Specs Buyers Must Freeze

Item	Published figure	Buyer note
Form / sockets	6U / 4 or 8	Write socket count on line 1
CPU	4th Gen Xeon Scalable; up to 480 cores; TDP up to 350 W; 4 UPI @ up to 16 GT/s	Not Xeon 6
Memory	up to 128 DDR5 RDIMM/3DS; 16 per CPU; 4800 MT/s @1 DPC; 4400 @2 DPC	Populate rules change speed
Drives	up to 24×2.5 SAS/SATA/NVMe; ICM 2×M.2; up to 2 SAS/RAID/trimode	No invented NF/0231 codes
NIC / slots	up to 4 hot-swap PCIe 5.0 x16 SFF OCP 3.0; 16×FHHL or 8×FHHL+4 dual-width GPU or 8 single-width GPU	GPU trades FHHL
Cooling / PSU	8 hot-swap dual-rotor N+1 fans; 4×CRPS 1300/1600/2000/2700 W N+M (M≤N)	Platinum or Titanium
Size / weight	482×263.2×870 mm with ears; full config <97 kg; inlet 5–45°C	White paper for envelope
SPEC example	8×8490H, 480 cores, 2 TB (64×32 GB), SPECrate2017_int_peak 3750	One published test — not default SKU

• Management: IPMI, SNMP, Redfish, TPM 2.0, BMC/BIOS redundancy.
• OS named: Windows Server, RHEL, SLES.
• Vendor RAS claim 99.999% — attribute to vendor, do not adopt as our measurement.
• No public net price. Soft corridors = industry estimate / pending confirmation.

4-Socket vs 8-Socket vs Dual 2-Socket Stack

Quick Answer: 8-socket wins single-image scale. Several 2-socket servers may win license math and blast radius. Never compare CapEx without writing socket count and license unit.

Dimension	TS860G7 4S	TS860G7 8S	Several 2S servers
Single OS image	Strong	Strongest core/DIMM ceiling	Split images
Max cores / DIMMs	Lower than 8S	Up to 480 / 128	Sum across boxes
Memory speed risk	1 DPC vs 2 DPC	2 DPC → 4400 MT/s	Per box rules
License unit	Write per chassis/core	Same	Often per socket/core × N

BOM Checklist Before PO

• Socket count: 4 or 8 on line 1.
• CPU SKU list — no invented Inspur order codes.
• DIMM population 1 DPC vs 2 DPC and resulting MT/s.
• Drive count ≤24 × 2.5-inch + M.2 plan.
• OCP + FHHL vs GPU tradeoff written.
• PSU wattage and N+M; fan N+1.
• Support years and OS entitlements.
• If dual-path vs 信创 2-socket stacks: label TS860G7 as imported multi-socket, not 信创.

HowTo: Check a TS860G7 RFQ Before You Compare It with Two 2-Socket Servers

1. Step 1 — Write socket count on line 1. State 4-socket or 8-socket explicitly before any price talk.
2. Step 2 — Match cores and DIMMs. Eight CPUs can reach 480 cores and 128 DIMMs; 2 DPC drops memory to 4400 MT/s.
3. Step 3 — Check GPU slot tradeoff. GPU rows replace half of the FHHL slots — count NICs after GPUs.
4. Step 4 — PSU and weight. Quote N+M CRPS and confirm full-config weight under 97 kg with facilities.
5. Step 5 — License vs scale-out. If comparing to several 2-socket servers, write whether software licenses are per chassis or per core.
6. Step 6 — Equal brief. Freeze the equal BOM for 双规比选 before channel confirmation.

Contact TAOHAN for China enterprise TS860G7 BOM review with 13% VAT special fapiao support — domestic delivery, not Hong Kong local stock as the main CTA.

Real-World Deployment Scenarios

1) Single-image HANA

Architecture needs one OS for a large memory footprint. 8-socket is justified. Failure mode: quote says “TS860G7” without socket count.

2) GPU + NIC squeeze

Four dual-width GPUs land; OCP/FHHL NICs disappear from the slot math. Fix: redraw slots after GPU rows.

3) False field upgrade

Buyer starts at 4 CPUs “to add 4 later.” Chassis/license may not allow it. Fix: ask before assuming.

FAQ

References

• IEIT TS860G7 product page
• SPEC CPU2017 result (8490H example)
• IEIT RAS / reliability note
