Quick Take
Quick Take: Treat PowerEdge R670 as a new platform. Pick E-core or P-core first, then DIMM speed, then the drive chassis. Copying an R660 BOM orders parts the 1U Xeon 6 server cannot use. For China enterprise RFQs, freeze the equal brief for 双规比选 before asking TAOHAN for 13% VAT special fapiao pricing.
What R670 Is (and Is Not)
Definition: Dell PowerEdge R670 is a 1U two-socket rack server for two Intel Xeon 6 processors — either E-core (up to 144 cores per CPU) or P-core (up to 86 cores per CPU). It is not an R660 with a refreshed BIOS. CPU, DIMM generation, and drive carriers are not interchangeable with R660.
Think of pasting an R660 BOM onto R670 like putting diesel in a petrol car: the rack unit looks similar, the fuel (CPU/DIMM/cage) is not. CXL 2.0 is supported only on Xeon 6 P-core per Dell’s technical guide. Optional direct liquid cooling (DLC) applies only to required CPU SKUs.
Fit: new 1U virtualization or dense NVMe builds.
Unfit: a GPU box that needs more than 3× 75 W single-wide accelerators.
Key Specs Buyers Must Freeze
Quick Answer: Two Xeon 6 CPUs, 32 DDR5 RDIMM slots up to 8 TB / 6400 MT/s, E3.S or 2.5-inch storage options, up to 3× PCIe Gen5 x16, optional DLC on marked CPUs, and firmware minima for certain P-core SKUs.
| Item | Published figure | Buyer note |
|---|---|---|
| Form / sockets | 1U / 2× Xeon 6 | E-core or P-core — write the letter |
| Sample E-core | 6710E 64C 205 W DDR5-5600; 6756E 128C 225 W DDR5-6400 | Confirm exact CPU PID on quote |
| Sample P-core | 6787P 86C 350 W DDR5-6400; 6767P class | CXL 2.0 on P-core only |
| Memory | 32 DDR5 RDIMM / up to 8 TB / up to 6400 MT/s | 16 DIMMs per CPU |
| Storage options | up to 8/16/20 E3.S; up to 8×2.5 SATA/NVMe/Universal; up to 10×2.5 SATA; up to 2 rear E3.S | Front-I/O vs rear-I/O differ |
| PCIe / OCP / GPU | up to 3×16 Gen5; 2× OCP 3.0; up to 3×75 W SW GPU | DPU example: BlueField-3 B3220 |
| PSU examples | 1400 W -48 VDC; 1800 W HLAC Ti; 1500 W 277 Vac/HVDC Ti | Do not invent a 1100 W SKU |
| Firmware example | 6787P/6767P need iDRAC 1.20.25.00, BIOS 1.2.6, FPGA 107.114.104 | Old iDRAC will not post new P-core |
- NIC speeds Dell names: 1/10/25/100/400 GbE.
- No public net price. Soft corridors = industry estimate / pending confirmation.
- On China pages, treat R670 as an imported dual-socket path — not a 信创 substitute label.
R670 vs R660 — Why One BOM Fails
Quick Answer: R660 is the previous 1U dual-socket Intel generation. R670 is Xeon 6. Shared option sets silently order wrong CPUs, DIMMs, and drive cages.
| Dimension | R670 | R660 (contrast) |
|---|---|---|
| CPU generation | Intel Xeon 6 (E or P) | 4th/5th Gen Xeon Scalable class |
| DIMM | 32× DDR5 up to 6400 | Not drop-in to R670 |
| Drive carriers | E3.S / 2.5 options as listed | Not interchangeable cages |
| CXL | P-core only | Do not assume from R660 habit |
| Quote rule | New platform worksheet | Separate line if still purchased |
BOM Checklist Before PO
- CPU letter: E-core or P-core + exact PID on the dated quote.
- DIMM count, capacity, and MT/s matched to that CPU.
- Drive chassis: E3.S vs 2.5-inch; front-I/O vs rear-I/O.
- PCIe / OCP / GPU / DPU lines within published envelopes.
- PSU from the published examples — no invented wattage SKUs.
- DLC only if Dell marks the CPU as requiring it.
- iDRAC/BIOS minima when reusing a chassis with new P-core CPUs.
- If R660 remains: second line, separate option set.
HowTo: Build an R670 RFQ from a Workload Instead of an R660 Spreadsheet
- Step 1 — Pick E-core or P-core. Choose Xeon 6 E-core or P-core first — DIMM speed and CXL follow the letter.
- Step 2 — Lock DIMM map. 32 DDR5 slots, 16 per CPU, up to 8 TB; confirm MT/s for the CPU SKU.
- Step 3 — Pick drive chassis. E3.S vs 2.5-inch / front-I/O vs rear-I/O are different cages — do not paste R660 carriers.
- Step 4 — Check DLC and firmware. If Dell marks DLC required, quote it; confirm iDRAC/BIOS minima for P-core examples.
- Step 5 — Separate mixed fleets. R660 leftovers stay on their own line — never one shared option matrix.
- Step 6 — Equal brief. Freeze the equal BOM for 双规比选 before channel confirmation.
Contact TAOHAN for China enterprise R670 BOM review with 13% VAT special fapiao support — domestic delivery, not Hong Kong local stock as the main CTA.
Real-World Deployment Scenarios
1) VM dense 1U refresh
Buyer pastes R660 CPU and DIMM rows onto R670. Quote fails configurator. Fix: pick E-core vs P-core, then DIMM speed.
2) E3.S vs 2.5-inch surprise
Storage team expects 2.5-inch carriers; chassis is E3.S. Drives do not seat. Fix: freeze cage type on the equal brief.
3) Mixed fleet PO
One spreadsheet mixes R670 new build and leftover R660 spares as one option matrix. Receiving chaos. Fix: two lines, two option sets.
FAQ
Is R670 a faster R660?
Do I need liquid cooling?
How much memory?
Can one quote mix R670 and R660?
References
- PowerEdge R670 spec sheet (PDF)
- PowerEdge R670 technical guide (PDF)
- R670 processor specifications (manual)
- Dell PowerEdge R670 product page
Key Takeaway
Key Takeaway: R670 is a new Xeon 6 platform. Do not reuse an R660 BOM. Lock E/P-core, DIMM speed, and drive chassis before price. TAOHAN supports China enterprise equal BOMs and 13% VAT special fapiao after the brief is frozen.
